Shop Brakes
Brake Lines

Brake Lines

Stock Replacement Lines
Stock Replacement Lines
more …
Burly Apehanger Cable and Line Kits
Burly Apehanger Cable and Line Kits
If you love the look of Apehangers, but hate sorting out which cables and brake line to use, you will like these complete cable/line control kits. No more trial, error and inventing of bad words that used to accompany mounting a set of Apehangers. Each kit is specific to a year range and bar height and includes extended throttle cables, extended clutch cable, extended brake line and even wiring harness extensions. One part# and you are all set.
more …
Goodridge Complete Brakeline Kits
Goodridge Complete Brakeline Kits
Pre-assembled, braided steel brake line kits with chrome-plated fittings. Certified, with installation instructions.
more …
Russel Cycleflex Brake Lines
Russel Cycleflex Brake Lines
Cycleflex OEM  replacement single brake lines have a PTFE inner liner combined with a stainless steel outer braid for smooth fluid transfer and a high burst strength. All end fittings are zinc plated.
more …
Goodridge Universal Braided Steel Brake Lines
Goodridge Universal Braided Steel Brake Lines
Stainless steel-braided, universal fit PTFE brake lines with screw-on fittings
more …
Goodridge Adapters for Universal Braided Steel Brake Lines
Goodridge Adapters for Universal Braided Steel Brake Lines
Fit our universal brake lines with AN-3 3/8” (JIC 37°) thread.
more …
DIY Braided Steel Brake Lines
DIY Braided Steel Brake Lines
Just the right thing for the experienced custom bike builder or racing nut. Top quality brake line with stainless steel braid sold by the meter. A wide selection of fittings is also available.
more …
DIY Brake Line Fittings
DIY Brake Line Fittings
A wide selection of fittings for the experienced mechanic for building shop-made brake lines.
more …
Stahlbus Banjo Bolts with Integrated Bleeder
Stahlbus Banjo Bolts with Integrated Bleeder
Banjo bolt for the connection of hydraulic brake and clutch hoses on motorcycles. Features an innovative, integrated quick bleeder valve, which allows, with one hand and unassisted, quick, clean and safe bleeding or refilling of your brake system. Installation of custom brake calipers or exchange of stock lines for braided steel hoses are significantly facilitated.
The main feature behind this is the special Stahlbus bleeder valve which remains completely sealed during the bleeding procedure; it is impossible for air to re-enter the system past the threads of the valve.
Description of the bleeding procedure:
attach bleeder hose (routed to a container) to the valve and open valve (1/2 turn), activate pump until all air bubbles have left the system (keep reservoir filled!), close valve - that's it,
Another advantage is that the valve is not screwed directly into the caliper, which is the case with standard nipples and where the frequent opening and closing damages the threads in the caliper.
The banjo bolt is precision machined on CNC equipment from anodised aluminium, the integrated quick-bleeder valve is made of nickel-plated and flash-chrome-plated steel.
more …
Stahlbus Bleeder Caps
Stahlbus Bleeder Caps
more …
Banjo Bolts
Banjo Bolts
more …
Banjo Bolts with Integrated Stop Light Switch
Banjo Bolts with Integrated Stop Light Switch
On custom projects often the question arises, where to put the brake light switch. These banjo bolts save searching time and additional brakeline tees and connections.
more …
Plugs for Brake Line T
Plugs for Brake Line T
more …
Brake Line T’s OEM Type
Brake Line T’s OEM Type
more …
Rick’s Brake Line T ABS
Rick’s Brake Line T ABS
Meticulously machined from billet aluminum these distributor fittings fit models with ABS brake systems. They replace the stock counterpart and mount to the bottom side of the lower triple tree.
more …
Front Brake Line T
Front Brake Line T
Designed to bolt under the lower triple tree. On the right side the bar takes two banjos, one from the master cylinder and one to the right caliper by using a double banjo bolt.
more …
Goodridge Brake Line T’s
Goodridge Brake Line T’s
more …
Brake Line Fittings Jic 37°-3 → 3/8”-24 IF
Brake Line Fittings Jic 37°-3 → 3/8”-24 IF
These adapters allow attachment of aftermarket brake lines to all OEM 3/8”-24 IF (inverted flare) connections.
more …
Brake Line Adapter 1/8-27” NPT→ 3/8”-24 IF
Brake Line Adapter 1/8-27” NPT→ 3/8”-24 IF
Brake line fittings for all handlebar-mounted master cylinders from 1972–81 as well as for the front and rear brake caliper on FL models from 1972–84 and rear caliper on FX 1973-82. Available either straight (for caliper) or 90°(for master cylinder).
more …
Brake Line Adapter 7/16”-24 → Jic 37°-3
Brake Line Adapter 7/16”-24 → Jic 37°-3
This stainless steel adapter allows to avoid the banjo/banjo-bolt connection on master cylinders 1982-up. It installs into the mastercylinder and the brake line can be directly attached.
more …
Brake Line Adapter 1/2”-20 → Jic 37°-3
Brake Line Adapter 1/2”-20 → Jic 37°-3
This stainless steel adapter allows for the use of custom braided steel brake lines on 1951-73 Servi-Cars with hydraulic rear brakes.
more …
Banjo Bolt Cover
Banjo Bolt Cover
Tricky chrome-plated die-cast cover for the unsightly brake line banjo bolts. Installs in minutes.
more …
Donnie Smith Brake Line Clamp
Donnie Smith Brake Line Clamp
Replace that plain looking stock clamp with this chrome-plated 2-piece metall clamp.
more …
Rubber Grommet Brake Line for FLT 1983-1985
Rubber Grommet Brake Line for FLT 1983-1985
more …
Cable and Line Clamps OEM Type
Cable and Line Clamps OEM Type
Bolt-on multi-purpose clamps. Fasten brake lines, control cables and wiring harnesses.
more …
Replacement Parts
Replacement Parts
Gaskets
Gaskets

Brake lines

Hydraulic brake lines on Harley-Davidsons such as Sportster, Softail, Dyna, Wide Glide or Electra Glide are the transmission between the hand or foot brake cylinder and the slave cylinder on the wheel. This is located inside the brake drum or in the brake caliper.

What are brake lines for Harleys made of?

There are three categories of materials that are used: Steel, rubber, or Teflon with braid.

Stock brake lines on Duo Glide, Electra Glide, Tour Glide and Sportster were made of steel or a combination of steel and rubber. Steel along the frame and rubber with steel connectors where the line needed to move. Among racers and customizers, "braided steel lines" caught on early. This is a flexible line with an inner tube made of Teflon, onto which a hose jacket made of interwoven steel threads is mounted. The swaged connections are also made of steel here. Steel flex offers high pressure resistance with good flexibility. The only thing you shouldn't do is kink the stuff. The rubber line has two disadvantages: it is flexible, which means that pressure is lost at the slave cylinder because the line inflates somewhat. And rubber ages, it becomes hard, brittle and porous. Those who choose rubber/steel lines for originality reasons must replace them regularly. Everyone else will be happy with steel/steel flex lines, they last forever and are available with a plastic coating on the outside to prevent chafing on the frame or tank.

Can I change brake lines myself? Can I make brake lines myself?

Twice YES! To change a brake line you need care, fresh seals, good tools and you have to be able to bleed brake lines. Hollow bolts are tightened with a torque wrench, which protects the sealing rings and the bolt itself. About 14 Nm must be enough, remember: the screw is hollow and it is missing just under 3 mm of material in the screw shaft core. You can assemble brake lines yourself. From prefabricated lines and suitable connectors such as banjos, banjo bolts, elbows and union nuts. We have everything at W&W Cycles, from brand manufacturers such as Russell, Krontec, Goodridge, for all in Germany, Austria and Switzerland preferably with parts approval.
