Replacement Parts for S&S Super E and Super G Carburetors



Replacement Parts for S&S Super E and Super G Carburetors

Picture courtesy of S&S Cycle Inc.









for S&S Super E/G carburetors

Item №

Version

net price*

unit

Availability in warehouse Germany

67-499

Bracket; for CV-Carburetor type cables (1990→); throttle cable ferrule height: 1-3/4”; steel, zinc plated

Bracket; for Keihin butterfly type cables (→1989); throttle cable ferrule height: 1/2”; steel, zinc plated

Dust boot; for Accelerator pump; also on S&S Two Throat carburetors; rubber

Ball; for Accelerator pump; also on S&S Two Throat carburetors; steel

Spring; for accelerator pump diaphragm; also on S&S Two Throat carburetors; steel

Diaphragm; for Accelerator pump; also on S&S Two Throat carburetors; rubber / steel

Float bowl; cast aluminum

Spring; for Ball check; spring steel

Screw; for cable clamp, float pin, fast idle lever; steel, zinc plated; button head with slot

Bolt; for Air cleaner backing plate / Butterfly carburetor; steel, zinc plated; thread: 1/4”-20; socket head

Bolt; for pump cap; steel, zinc plated; fillister head slot

Lever; for Starter plunger; for Super E/G Buell and A/C of pre-4-95 production; steel, zinc plated

Adjusting screw; for Accelerator pump; steel, zinc plated; fillister head slot

Spring; for idle speed/accelerator pump adjuster; spring steel

Axle; for Float; brass

Bolt; for idle speed adjustment; steel, zinc plated; fillister head slot

Pushrod; for Accelerator pump; steel

Bolt; for Float bowl; steel, zinc plated; thread: #10-24; thread length: 2-3/8; fillister head slot

Lever; for Starter plunger; steel, zinc plated

Starter plunger; stainless steel

Valve seat »Style C«; for Float valve; brass; thread: 1/2”-20

Nut; for Starter plunger; brass; hex

Spring; for fast idle plunger; spring steel

Vent and overflow line; PVC; length: 60 cm; inner Ø: 0.125 ”; outer Ø: 0.25 ”

Gasket by S&S; for Air cleaner / Butterfly carburetor; S&S Super E/G carburetors and air filters or CV carburetors and S&S air filters for OEM carburetors; paper; gross weight: 1 g

Protective cover by S&S; for Fuel line; plastic, black; length: 30 cm; Ø 20 mm; gross weight: 36 g

Idle mixture screw by S&S; for S&S Super E and G carburetors; brass, with O-ring groove; NOTE: does not fit early production E/G carbs with O-ringless mixture screws; gross weight: 7 g

O-Ring by S&S; for Idle adjuster screw; S&S Super E/G carburetors; fluoroelastomer; ID x OD: 3 x 5 mm, 1 mm thick ; gross weight: 1 g

Fitting by S&S; for S&S Super E and G carburetors; for 5/16” ID fuel lines; brass / steel, 90°/360°; with 17” fuel line, gasket, float valve, hose clamps; USA; gross weight: 149 g

Main nozzle by S&S; for S&S Super B, E, and G carburetors; brass; gross weight: 25 g

Wave washer by S&S; for Lever / Starter plunger; steel, zinc plated; gross weight: 1 g

Washer by S&S; for Lever / Starter plunger; nylon; gross weight: 1 g

Washer by S&S; for Lever / Starter plunger; steel, zinc plated; gross weight: 1 g

Bushing by S&S; for Lever / Starter plunger; brass; gross weight: 2 g

Float »Type C« by S&S; for S&S Super B, E, and G carburetors; plastic; gross weight: 10 g

Float needle »Type C« by S&S; for S&S Super B, E, G and Twothroat carburetors; steel / Viton; gross weight: 3 g

O-Ring by S&S; for Accelerator jet; S&S Super E/G carburetors; fluoroelastomer; ID x OD: 2.9 x 6.5 mm, 1.8 mm thick ; gross weight: 1 g

O-Ring by S&S; for Float valve; S&S Super E/G carburetors; fluoroelastomer; ID x OD: 10 x 13 mm, 1.5 mm thick ; gross weight: 1 g

Idle mixture screw by S&S; for S&S Super B, E, and G carburetors; brass; gross weight: 10 g

O-Ring by S&S; for Butterfly carburetor / Insulator block / Manifold; for S&S Super G carburetors; rubber; ID x OD: 57.1 x 60.7 mm, 1.8 mm thick; gross weight: 10 g

O-Ring by S&S; for Cover / Accelerator pump; S&S Super E/G carburetors; fluoroelastomer; ID x OD: 5.2 x 9 mm, 1.9 mm thick ; gross weight: 1 g

Gasket by S&S; for Float bowl; S&S Super E/G carburetors; paper; gross weight: 10 g

O-Ring by S&S; for Butterfly carburetor / Insulator block / Manifold; for S&S Super E carburetors; rubber; ID x OD: 50.7 x 54.3 mm, 1.8 mm thick; gross weight: 1 g

Screw by S&S; for Throttle disc; for S&S Super B, E, and G carburetors; steel, zinc plated; thread: #6-32; length: 1/4 ” (6 mm); Torx button head; wrench size: T15; gross weight: 10 g

Spring by S&S; for Idle adjuster screw; for S&S Super B, E, and G carburetors; spring steel; gross weight: 1 g

Throttle disc by S&S; for S&S Super B and E carburetors; brass; Ø 1-7/8”; gross weight: 20 g

Screw by S&S; for Float bowl; for S&S Super B and Twothroat carburetors; steel, zinc plated; thread: #10-24; thread length: 3/4; gross weight: 4 g

Drain plug by S&S; for Float bowl; for S&S Super B, E, G and Two Throat carburetors; also on S&S Two Throat carburetors; brass; thread: 1/2”-20; gross weight: 10 g

* Tax free shipping.
