>Carburetor and Injection
>Replacement Parts for S&S Super B
Availability in warehouse Germany
Bushing; for Throttle shaft; for S&S Super B carburetors; steel; length: 12.7 mm; inner Ø: 6.4 mm; outer Ø: 8 mm
Lever; for Throttle shaft; for S&S Super B carburetors; for 2 cables; cast aluminum / steel
Float needle »Type C«; for S&S Super B, E, G and Twothroat carburetors; steel / Viton
Screw; for Throttle disc; for S&S Super B, E, and G carburetors; steel, zinc plated; thread: #6-32; length: 1/4 ” (6.4 mm); Torx button head; wrench size: T15
Spring; for Idle adjuster screw; for S&S Super B, E, and G carburetors; spring steel
Screw; for Float bowl; for S&S Super B and Twothroat carburetors; steel, zinc plated; thread: #10-24; thread length: 3/4
Drain plug; for Float bowl; for S&S Super B, E, G and Two Throat carburetors; also on S&S Two Throat carburetors; brass; thread: 1/2”-20
Idle mixture screw; for S&S Super E and G carburetors; brass, with O-ring groove; NOTE: does not fit early production E/G carbs with O-ringless mixture screws
Protective cover by S&S; for Fuel line; plastic, black; length: 30 cm; Ø 20 mm; gross weight: 36 g
Gasket by S&S; for Air cleaner / Butterfly carburetor; S&S Super B carburetors and air filters; paper; gross weight: 2 g
O-Ring by S&S; for Butterfly carburetor / Insulator block / Manifold; for S&S Super B carburetors; rubber; ID x OD: 52 x 57 mm, 2.5 mm thick; gross weight: 2 g
Enrichment device »Super B type« by S&S; for S&S Carbs; stainless steel / brass, 1 stage; gross weight: 30 g
Gasket by S&S; for Float bowl; S&S Super B carburetors; paper; gross weight: 10 g
* United States of America: Tax free shipping. Please check your local import fees.
Fuel Line Insulator
Flexible insulator tube which protects the fuel line from scuffing or against heat influence when running it between the cylinders.
