Replacement Parts for Star Hub 1936-1966



Replacement Parts for Star Hub 1936-1966

Replacement Parts for Star Hub 1936-1966

for Star hub 1936-1966

Item №

Version

net price*

unit

Availability in warehouse Germany

27-010

Cover; sheet steel, chrome-plated, without hole for grease fitting; replaces OEM HD 43566-35

Cover; sheet steel, CAD (ZnNi process), without hole for grease fitting; replaces OEM HD 43566-35

Cover; sheet steel, parkerized, without hole for grease fitting; replaces OEM HD 43566-35

Cover; sheet steel, chrome-plated, with hole for grease fitting; replaces OEM HD 43566-35A

Cover; inner; steel, bare; replaces OEM HD 3974-35, and 43574-35

Covers; steel / cork, outer and inner; with screws and gaskets; replaces OEM HD 43566-35A, 43570-35, and 43574-55

Shim; steel; ID x OD: 25.9 x 44.2 mm, 0.05 mm thick; replaces OEM HD 43560-35

Thrust washer; steel; replaces OEM HD 43563-35

Spacer; for Thrust washer; steel; replaces OEM HD 43556-35

Bearing retainer; also used for: 1936-1954 Big Twin Engine Case Bearing left; steel; tolerance class: ABEC 1; ID x OD: 1 x 1.5”; with std. rollers; replaces OEM HD 417-30, and 24721-30

Thrust washer; steel; ID x OD: 25.9 x 36.9 mm, 2.3 mm thick; replaces OEM HD 43552-39

Bearing collar; steel; replaces OEM HD 43561-39

Roller bearing sleeve; steel; replaces OEM HD 43550-35

Bearing retainer; also used for: bearing right side engine case Big Twins 1958→; steel; with std. rollers; replaces OEM HD 43578-35

Thrust washer; steel; ID x OD: 35.6 x 44.3 mm, 0.8 mm thick; replaces OEM HD 43558-39

Snap ring; for Thrust washer; spring steel; replaces OEM HD 43554-35

Cover; for cork seal; steel; replaces OEM HD 43564-35

Bearing roller; for sprocket-shaft Big Twin 1930-57, pinion-shaft Big Twin 1958-86, main shaft left roller bearing IOE 1925-1928 and V models 1930-1936, main shaft right roller bearing Singles, D and R models 1926-1934 , Star hubs →1966; steel, ground; length: 0.490”; Ø 0.250”; Over-/Undersize: +0.000 ”; tolerance class: ABEC 1; replaces OEM HD 2289-25, and 9220A; gross weight: 3 g

Bearing roller; for sprocket-shaft Big Twin 1930-57, pinion-shaft Big Twin 1958-86, main shaft left roller bearing IOE 1925-1928 and V models 1930-1936, main shaft right roller bearing Singles, D and R models 1926-1934 , Star hubs →1966; steel, ground; length: 0.490”; Ø 0.2502”; Over-/Undersize: +0.0002 ”; tolerance class: ABEC 1; replaces OEM HD 2289-25D, and 9221A; gross weight: 3 g

Bearing roller; for sprocket-shaft Big Twin 1930-57, pinion-shaft Big Twin 1958-86, main shaft left roller bearing IOE 1925-1928 and V models 1930-1936, main shaft right roller bearing Singles, D and R models 1926-1934 , Star hubs →1966; steel, ground; length: 0.490”; Ø 0.2504”; Over-/Undersize: +0.0004 ”; tolerance class: ABEC 1; replaces OEM HD 2289-25F, and 9222A; gross weight: 2 g

Bearing roller; for sprocket-shaft Big Twin 1930-57, pinion-shaft Big Twin 1958-86, main shaft left roller bearing IOE 1925-1928 and V models 1930-1936, main shaft right roller bearing Singles, D and R models 1926-1934 , Star hubs →1966; steel, ground; length: 0.490”; Ø 0.252”; Over-/Undersize: +0.002 ”; tolerance class: ABEC 1; replaces OEM HD 9226; gross weight: 3 g

Bearing roller; for sprocket-shaft Big Twin 1930-57, pinion-shaft Big Twin 1958-86, main shaft left roller bearing IOE 1925-1928 and V models 1930-1936, main shaft right roller bearing Singles, D and R models 1926-1934 , Star hubs →1966; steel, ground; length: 0.490”; Ø 0.2506”; Over-/Undersize: +0.0006 ”; tolerance class: ABEC 1; replaces OEM HD 2289-25H, and 9223A; gross weight: 2 g

Bearing roller; for sprocket-shaft Big Twin 1930-57, pinion-shaft Big Twin 1958-86, main shaft left roller bearing IOE 1925-1928 and V models 1930-1936, main shaft right roller bearing Singles, D and R models 1926-1934 , Star hubs →1966; steel, ground; length: 0.490”; Ø 0.251”; Over-/Undersize: +0.001 ”; tolerance class: ABEC 1; replaces OEM HD 2289-25MA, and 9225A; gross weight: 3 g

Bearing roller; for sprocket-shaft Big Twin 1930-57, pinion-shaft Big Twin 1958-86, main shaft left roller bearing IOE 1925-1928 and V models 1930-1936, main shaft right roller bearing Singles, D and R models 1926-1934 , Star hubs →1966; steel, ground; length: 0.490”; Ø 0.2508”; Over-/Undersize: +0.0008 ”; tolerance class: ABEC 1; replaces OEM HD 2289-25XA, and 9224A; gross weight: 3 g

Bolt/screw kit by Colony; for Star hub 1936-1966; steel, chrome-plated; button head with slot; replaces OEM HD 2756, and 7230; USA; gross weight: 30 g

Bolt/screw kit by Colony; for Star hub 1936-1966; steel, CAD (ZnNi process); button head with slot; replaces OEM HD 2756, and 7230; USA; gross weight: 30 g

Bolt/screw kit by Colony; for Star hub 1936-1966; steel, parkerized; button head with slot; replaces OEM HD 2756, and 7230; USA; gross weight: 30 g

Roller bearing sleeve; for Star hub 1936-1966; steel, +0,2 mm on small end; Germany; gross weight: 280 g

Grease nipple; for Seat post unit; fits 1939→ models; straight; steel, zinc plated; thread: 5/16”-32; replaces OEM HD 9851B; gross weight: 10 g

Serrated washer »external«; steel, parkerized; outer Ø: 1/2 ”; nominal ID: 1/4”; replaces OEM HD 7230; gross weight: 1 g

Gasket kit by James Gaskets; for Star hub 1936-1966; paper / cork; replaces OEM HD 43570-35, 43571-35, and 43576-35; gross weight: 10 g
