Stripped bleeder screw threads can be easily fixed with these inserts, which re-establish the stock 3/8”-24 threads. You will need a 7/16"-20 tap.

These oil line kits allow installation of a pressure gauge to the rocker box and thus to read oil pressure while riding. The lower end line fitting screws into the engine case. Gauge not included.

After decades during which exhaust headers on Harley-Davidson motorcycles were simply inserted into the cylinders (heads) or clamped in place, the engineers in Milwaukee came up with a screw connection for the Shovelhead cylinder heads of the big twins from 1966–1984. The required internal hex screw was simply threaded into a single tapped hole in the flange on the cylinder head. The disadvantages of this system should not be overlooked: the fastening is not symmetrical; sooner or later the flange will warp and the gasket will start leaking again, the thread in the cylinder head is stressed every time the screw is tightened or loosened (a better alternative would be a stud), there are no torque specifications from Harley-Davidson for this screw. In many cases, this leads to the screw being overtightened, with corresponding damage to the thread, When dealing with this screw, it is therefore best to proceed with care, not to exceed 18 Nm, and to avoid retightening it when the engine is hot.

Selection of cam shims to establish the correct sideplay of all Flathead and Sportster models 1937-1985.

These pushrods replace the factory steel pushrods. They were designed for use with hydraulic units but weigh less than the stock parts.

Bolt kit by Bender Cycle; for Shock absorbers; fits Softail 1987-2017; steel, zinc plated; with washers; replaces OEM HD 4074A, and 6724; gross weight: 350 g

Repair kit by Bender Cycle; for Banana style calipers; fits FL, FX 1973-1983; steel, browned / zinc plated; thread: 1/2”-20; replaces OEM HD 44331-73, 44124-72, 45821-75, and 45822-75; gross weight: 120 g

Bushing by Bender Cycle; for Banana style calipers / Caliper mounting bracket; fits FL, FX 1973-1983; steel, browned ; length: 15 mm; replaces OEM HD 45822-75; gross weight: 10 g

Bushing by Bender Cycle; for Banana style calipers / Caliper mounting bracket; fits FL, FX 1973-1983; steel, browned ; length: 20 mm; replaces OEM HD 45821-75; gross weight: 10 g

Mounting pin by Bender Cycle; for Brake pads; for Banana style calipers; fits FL, FX 1973-1983; steel, zinc plated; replaces OEM HD 44124-72; gross weight: 20 g

Mounting pin by Bender Cycle; for Bushing; for Banana style calipers; fits FL, FX 1973-1983; steel, browned ; replaces OEM HD 44107-72; gross weight: 80 g

Pin by Bender Cycle; for Brake caliper; fits Sportster, FX 1977-1983; steel; position: front; replaces OEM HD 44162-77; gross weight: 10 g

Bushing by Bender Cycle; for Brake caliper; fits Sportster, FX 1977-1983; steel, L1: 13.4mm / L2: 19.5mm; position: front; ID x OD: 9.6 x 12 mm; replaces OEM HD 46019-77; gross weight: 10 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 1.27 mm; replaces OEM HD 25550-36; USA; gross weight: 3 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 1.40 mm; replaces OEM HD 25551-36; USA; gross weight: 3 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 1.52 mm; replaces OEM HD 25552-36; USA; gross weight: 3 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 1.65 mm; replaces OEM HD 25553-36; USA; gross weight: 3 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 1.78 mm; replaces OEM HD 25554-36; USA; gross weight: 3 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 1.91 mm; replaces OEM HD 25555-36; USA; gross weight: 3 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 2.03 mm; replaces OEM HD 25556-79; USA; gross weight: 4 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 2.16 mm; replaces OEM HD 25557-79; USA; gross weight: 4 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 2.29 mm; replaces OEM HD 25558-79; USA; gross weight: 4 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 2.41 mm; replaces OEM HD 25559-79; USA; gross weight: 4 g

Cam shim by Bender Cycle; fits Big Twins OHV 1936-1999; steel; thickness: 2.54 mm; USA; gross weight: 4 g

Thrust washer by Bender Cycle; for Flywheels; fits OHV BT 74“/80“ 1941-1999, Sportster 1972-early 1987; brass, precision ground; ID x OD: 35.7 x 53.1 mm, 1.52 mm thick; replaces OEM HD 6505, 6506, and 23973-41; USA; gross weight: 36 g
