JAE MX19 Connector System

JAE MX19 Connector System

Introducing the CAN-Bus by the Factory required new connectors for low current applications on lighting and handlebar controls. These wire connections have to be especially protected due to the way the CAN-Bus works.

The MX19 connector series stands out for the following:

  • Being waterproof
  • Mechanical positive lock
  • Additional protection for the wire insulation on the rear of the connector housings
  • Small dimensions
  • Ok for currents up to 5 A

2-Way
2-Way

more …
4-Way
4-Way

more …
Terminal Pins and Sockets
Terminal Pins and Sockets

more …
Seal Pins
Seal Pins
If one connector hole is not used a seal pin for the unused cable hole is required.
more …

See also:

Electric Wires Standard - 0.5 mm²

Electric Wires Standard - 0.5 mm²

more …
Electric Wires Standard - 0.34 mm²

Electric Wires Standard - 0.34 mm²

more …
Permatex Tune-Up Dielectric Grease

Permatex Tune-Up Dielectric Grease

This dielectric grease is designed for any type of electrical connections and terminals. Applications are spark plug connectors, battery terminals, plugs, switches, bulbs, ignition coil terminals and fuses, which are efficiently protected from dirt, moisture, salt and corrosion. Before application, surfaces should be cleaned, and the ignition switched off.
more …
Engineer PA-20 Crimptool

Engineer PA-20 Crimptool

Crimp tool for small and medium sized connector pins as used for example with JAE MX19. Precise and universal crimping.
more …
