Grip Spirals for Models 1953-1974
- Grip spiral »Pull Type«
- for Bendix carburetors
- fits FL 1971-1974, FX 1971-1973, XL 1972-1973
- Bendix and other later style carbs
- steel, chrome-plated
- replaces Harley-Davidson part number HD 56220-58
- gross weight: 170 g
Handlebar Spirals →1970
Throttle spiral grips on early model Harleys differ from common versions in that they push the cable rather than pulling it. This is made possible by using stiff steel cores instead of flexible braided inner cables.
Later carburetors 1971→ require pull action, so the factory changed to pull type grips in that year. For Custom applications using pull action carbs with early handlebars W&W also offers special pull type spiral grips.
Last but not not least
The Factory used the same spiral grips on both sides. That means, when using a push type grip as timer control on the left side of the handlebars the function is reversed, i.e. it pulls.
