Electrical

11-537

Battery »AG-1201/12-Cell« by Antigravity; replaces a 12 Ah AGM battery; W x H x D: 115 x 108 x 79 mm; net weight: 1.2 kg; 12 V; 7.5 Ah; energy rating: 96 Wh; cold cranking current (SAE): 360 A; pole connections: M6 (screws included); with adhesive backed foam mats; gross weight: 1.21 kg

more …

14-028

Ignition switch; fits Dyna 1990-2005 (exc. FXDWG), Sportster 1990-2013; with 3 Key Positions OFF - IGNITION - IGNITION + LIGHT ON; steel; with two keys; gross weight: 220 g

more …

13-330

Actuating lever; fits chain drive 4-speed Big Twin →1985; steel; replaces OEM HD 31445-65A, and 31445-85; gross weight: 60 g

more …

13-371

Bushing; for Starter shaft; fits FL 1965-1982, FLT 1980-1984, FX 1971-1985 (exc. Belt Drive models), FXR 1982-1984, Servi-car 1966-1973; steel; replaces OEM HD 11041; gross weight: 10 g

more …

13-372

Stud; for starter shaft housing; fits Big Twins 1965-1978; steel, parkerized; replaces OEM HD 24811-59A; gross weight: 10 g

more …

13-374

Starter shaft; fits FL 1970-1982, FX 1971-1985 (exc. Belt Drive models); steel; length: 175 mm; gross weight: 250 g

more …

13-376

Thrust washer; for Starter shaft; fits XL 1967-1980, FL 1965-1984, FLT 1980-1988, FX 1971-1985 (exc. Belt Drive models), FXR 1982-1986, FXST bis 1988; copper; replaces OEM HD 31502-65; gross weight: 12 g

more …

13-377

Shifter collar; fits FL 1970-1984, FX 1971-1985 (4-speed, exc. Belt Drive models); steel; replaces OEM HD 31503-70; gross weight: 70 g

more …

13-378

Spacer; for Starter shaft; fits FL 1965-1982, FX 1971-1985 (exc. Belt Drive models), Servi-car 1966-1973; steel; replaces OEM HD 31531-69; gross weight: 70 g

more …

13-678

Starter motor by Spyke; fits Big Twin 1965 - early 1979; black; 1.4 kW; gross weight: 3.46 kg

more …

91-196

Bracket; for Regulator; fits 4 -speed Big Twin 1976-1986, Softail →1999 ; steel, chrome-plated; replaces OEM HD 74533-75TB, and 74534-80; gross weight: 340 g

more …

13-370

Snap ring; fits XL 1967-1980, FL 1965-1984, FLT 1980-1988, FX 1971-1985 (exc. Belt Drive models), FXR 1982-1988, FXST bis 1988, Servi-car 1966-1973; spring steel; replaces OEM HD 11039; USA; gross weight: 40 g

more …

80-505

Bolt; for Actuating lever; fits Big Twin 4-Speed 1965-1984 ; holds the starter gear shifter lever; steel, chrome-plated; replaces OEM HD 31478-65A; gross weight: 30 g

more …

13-797

Plunger; fits Big Twin 1965-1988, Sportster 1967-1980; steel; replaces OEM HD 31435-65B; gross weight: 180 g

more …

86-053

Lock washer »Standard«; steel, zinc plated; nominal ID: 1/4 ”; replaces OEM HD 7036; gross weight: 1 g

more …

86-506

Screw; steel, zinc plated; hex; thread: 1/4”-20; length: 1-1/2 ” (38 mm); wrench size: 7/16 ”; replaces OEM HD 2872W; gross weight: 10 g

more …

13-416

Starter gear by Accel; fits Sportster 1967-1980, Big Twin 1965-1988; steel; replaces OEM HD 31443-65TA; gross weight: 300 g

more …

13-399

Boot; for Plunger; fits Big Twin 1965-1988, Sportster 1967-1980; inner; rubber; replaces OEM HD 31441-65A; gross weight: 10 g

more …

13-400

Cover; for Solenoid; fits Big Twin 1965-1988, Sportster 1967-1980; rubber, black; replaces OEM HD 31475-77; gross weight: 40 g

more …

13-403

Solenoid by Accel; fits FL and FX models 1965-1988, Softail →1988, Sportster 1967-1980, Servi Car 1966→; steel / plastic, zinc plated; replaces OEM HD 71469-65, and 71473-77; China; gross weight: 800 g

more …

13-413

Retainer; for Spring / Plunger; fits Big Twin 1965-1988, Sportster 1967-1980; steel; replaces OEM HD 31439-84; gross weight: 10 g

more …

13-414

Spacer; fits 4-speed Big Twin 1965→, Softail →1988, Sportster 1967-1980; steel, zinc plated; replaces OEM HD 31452-65A; gross weight: 30 g

more …

13-748

Charging system by Spyke; fits Big Twin 1970-1999 (exc. Twin Cam); 32 A; with black regulator; gross weight: 3.65 kg

more …

13-773

Screw; for stator; fits Big Twin 1970-early 1985 (FL/FX/FXST 1985), Sportster Late 1984 (for stator flange, 8-hole stator mount); steel, zinc plated; fillister head Phillips; thread: #10-24; length: 7/8 ” (22 mm); replaces OEM HD 2653; USA; gross weight: 10 g

more …

13-776

Locking plate; for Stator; fits Big Twin 1970-1986; steel; replaces OEM HD 29988-73; gross weight: 9 g

more …

13-830

Shim; for Rotor; fits Big Twin 1970-1988; steel, ground; ID x OD: 28.6 x 69.7 mm, 4 mm thick ; gross weight: 200 g

more …

14-129

Pin housing »DT« by Deutsch; 12-way; polyamide, black; L x W x H: 44 x 34 x 22 mm; for wires: ~ 0.5 - 2.5 mm² (AWG 20-14); replaces OEM HD 72109-94BK; USA; gross weight: 20 g

more …

14-139

Pin lock »DT« by Deutsch; for Terminal pin; 12-way; polyamide; for wires: ~ 0.5 - 2.5 mm² (AWG 20-14); replaces OEM HD 72149-94; USA; gross weight: 20 g

more …

14-159

Socket housing »DT« by Deutsch; 12-way; polyamide, black; L x W x H: 31 x 40 x 18 mm; for wires: ~ 0.5 - 2.5 mm² (AWG 20-14); replaces OEM HD 72119-94BK; USA; gross weight: 10 g

more …

14-169

Socket lock »DT« by Deutsch; for Terminal socket; 12-way; polyamide; for wires: ~ 0.5 - 2.5 mm² (AWG 20-14); replaces OEM HD 72159-94; USA; gross weight: 10 g

more …

95-343

Wire clip; for Handlebars 1982→; nylon, black; Ø 1/2”; replaces OEM HD 70345-84; USA; gross weight: 10 g

more …

95-349

Cable tie; plastic, black; length x width: 360 x 4.8 mm; gross weight: 1 g

more …

69-531

Spring; for Solenoid; for solenoid plunger; fits Big Twin 1965-1988, Sportster 1967-1980; spring steel; replaces OEM HD 31438-65A; gross weight: 50 g

more …

69-532

Spring; for solenoid plunger; fits Big Twin 1965-1988, Sportster 1967-1980; spring steel; replaces OEM HD 31440-65; USA; gross weight: 10 g

more …

28-306

Clamp; for 9.8 mm Ø wire looms; metal, black, rubber covered, mounting hole 5 mm; replaces OEM HD 38712-68; gross weight: 7 g

more …

29-376

Banjo bolt by Goodridge; with integrated stoplight switch; 2,8 mm spade terminals; stainless steel; thread: 3/8”-24; gross weight: 30 g

more …

95-350

Cable tie; plastic, black; length x width: 290 x 3.6 mm; gross weight: 10 g

more …

57-776

Gasket kit by James Gaskets; for Starter housing; fits FLH 1965-1982, FX 1971-1985 (except Belt Drive models); rubber / steel; replaces OEM HD 60516-65A, 60559-80, 11101, and 31478-65A; gross weight: 90 g

more …
