Chassis

16-090
16-090
Shock absorbers »Regular« by Progressive Suspension; fits FL/FX 1973-1985; steel / spring steel, chrome-plated; length: 280 mm; shock eyelet: 12.9 mm; spring rate: 300/350 lbs/inch; with spring adjustment wrench; with parts certificate; gross weight: 4.76 kg
more …
16-052
16-052
Stud kit; for Shock absorbers; fits FL/FX 1973-1985; top; steel, zinc plated; length: 125 mm; thread: 5/8”-18 / 3/8”-24; shock eyelet: 12.7 mm; with 2 studs, 4 chrome washers; replaces OEM HD 54515-73; gross weight: 390 g
more …
16-058
16-058
Stud kit; for Shock absorbers; fits FL/FX 1973-1985; bottom; steel, zinc plated; length: 75 mm; thread: 1/2”-20; shock eyelet: 12.7 mm; with 2 studs, 2 chrome nuts and 2 chrome washers; replaces OEM HD 3958; gross weight: 230 g
more …
91-055
91-055
Cover; for Stud / Shock absorbers; fits Sportster 1965-1974, FL/FX 1970-1985; sheet steel, chrome-plated; replaces OEM HD 54704-65TA; gross weight: 60 g
more …
46-200
46-200
Jiffy stand; fits Big Twin 4-speed 1936-1984 (exc. FXWG); 50013-74A; steel, chrome-plated, standard length; Length according to drawing: 27 cm; gross weight: 1.3 kg
more …
16-002
16-002
Swingarm axle; fits Big Twin 4-speed 1958-1986; steel, chrome-plated; thread: 5/8”-18; replaces OEM HD 47510-58; gross weight: 480 g
more …
26-519
26-519
Spacer; for Swingarm axle; fits Big Twin 4-speed 1958-1986; steel, zinc plated; replaces OEM HD 47517-58; gross weight: 30 g
more …
69-312
69-312
Tab washer; for swingarm axle; fits Big Twin 4-speed 1958-1986; steel; replaces OEM HD 47513-58; gross weight: 10 g
more …
85-520
85-520
Adjustment bolts; for Rear axle; fits 4-speed Big Twin 1973→ (except FXST) and Sportster 1979-1996; steel, chrome-plated; with chrome-plated end caps and nuts; replaces OEM HD 47554-73, 41570-77, and 7725; gross weight: 270 g
more …
27-028
27-028
Grease nipple; for Seat post unit; fits 1939→ models; straight; steel, zinc plated; thread: 5/16”-32; replaces OEM HD 9851B; gross weight: 10 g
more …
85-800
85-800
Dust cover; for Bleeder screw / Grease nipple; rubber, black; inner Ø: 4.5 mm; replaces OEM HD 44271-74; gross weight: 1 g
more …
57-183
57-183
Oil seal by James Gaskets; for Axle spacer / Wheel hub / Swingarm; fits FL cast wheel front and rear 1973-1982, FX and Sportster front 1973-1982, Sportster 1979-1983 rear, FLT 1982-1984 and FXRT 1984, left/ also 4-speed Big Twin swingarms from 1973-1986; rubber / steel; ID x OD: 28.6 x 45.4 mm; 8 mm thick; replaces OEM HD 47519-72; gross weight: 10 g
more …
