Replacement Parts for Generators 58 and 65A Type



Replacement Parts for Generators 58 and 65A Type

Replacement Parts for Generators 58 and 65A Type

Item №

Version

net price*

unit

Availability in warehouse Germany

13-693

Bearing support plate; steel / cast aluminum; with bearing; replaces OEM HD 30095-61

Repair kit; for Generator; for 2-brush generators 1958-1981; steel / paper / plastic; replaces OEM HD 2690W, 31098-58, and 7634

Needle bearing; for Generator; for armature commutator end; fits Big Twin 1958-1969, Sportster 1958-1981; steel, closed end; OD: 17.5 mm, 12.6 mm thick; replaces OEM HD 9088; USA

Field coils by Cycle Electric; for 12-volt generators; fits Big Twin 1965-1969, Sportster 1965-1981; copper; replaces OEM HD 30201-65; USA

Field coils by Cycle Electric; for Generator; copper; 6 V; replaces OEM HD 30201-58

Nut; for Generator / Terminal pin; also usable for: ignition coil terminals 1965-1999; brass; hex head; thread: #10-32; replaces OEM HD 7634

Armature by Cycle Electric; for Generator; fits Big Twin 1965-1969, Sportster 1965-1981; replaces OEM HD 30851-65TA; USA

Screws; for field coil shoes; fits Big Twin 1958-1969, XL 1958-1981; steel; thread: 3/8”-24; replaces OEM HD 30280-58

Brush set by Accel; for all 2-brush generator 6 and 12 V; fits FL 1958-1969, Sportster 1958-1981; replaces OEM HD 30426-58; NOTE: Generator brush sets will not fit fan-cooled generators!

Brush set; for 12 V 2-brush generators; fits XL 1982 - early 1984; replaces OEM HD 29913-82; USA; NOTE: Generator brush sets will not fit fan-cooled generators!

Screws; for Wire terminals; for 2-brush generators 1958→; steel / brass / bakelite; with nuts and insulation; replaces OEM HD 2690W, 31097-58, 7634, 5911, 6186, and 7634

Spring; for generator brushes; spring steel; replaces OEM HD 30453-58

Snap ring; 2 per generator; spring steel; replaces OEM HD 11004

Cover; for generator brushes; steel, black, powder-coated; replaces OEM HD 30475-66

Cover; for generator brushes; steel, chrome-plated; replaces OEM HD 30475-66

Nut »Nyloc«; steel, zinc plated; hex head self-lock; thread: 5/16”-24; gross weight: 10 g

Oil deflector; for Generator; for 58 and 65A; fits Big Twin 1958-1969, Sportster 1958-1981, Servi-car 1958-1965; steel; replaces OEM HD 31035-58; gross weight: 20 g

Oil deflector; for Generator; for 58 and 65A; fits XL 1963-1981; steel; replaces OEM HD 31067-63; gross weight: 20 g

Drive gear; for Generator; for 58 and 65A; fits Big Twin 1958-1969; 13 teeth; steel; replaces OEM HD 31070-58; gross weight: 40 g

Drive gear; for Generator; for 58 and 65A; fits XL 1963- early 1984; 14 teeth; steel; replaces OEM HD 31073-63, and 31073-63A; gross weight: 40 g

Ball bearing; for 32E and 52 type 3-brush generators, 58/65A 2 brush generators, and Servi Car alternator drive shafts; fits WL, K 1949-1957, Big Twin 1949-1969, Sportster 1957-1981, Servi Car 1949→; armature drive gear end; steel; tolerance class: ABEC 5; ID x OD: 15 x 35 mm, 11 mm thick; replaces OEM HD 9007; gross weight: 40 g

Washer; for chain tensioner on square section swing arms, exhaust clamp bolts; steel, zinc plated; outer Ø: 17.5 mm; nominal ID: 8 mm; thickness: 2 mm; replaces OEM HD 6324W; USA; gross weight: 3 g

Drive gear by Cycle Electric; for Generator; for 58 and 65A; fits XL 1963- early 1984; 14 teeth; steel; replaces OEM HD 31073-63, and 31073-63A; gross weight: 43 g

Drive gear by Cycle Electric; for Generator; for 58 and 65A; fits Big Twin 1958-1969; 13 teeth; steel; replaces OEM HD 31070-58; gross weight: 37 g

Oil seal; for Bearing / Armature / Generator; for 58/65A brush side; fits Big Twin 1958-1969, Sportster 1958-1981; steel / rubber; replaces OEM HD 12002; gross weight: 6 g

Oil seal; for Bearing / Armature / Generator; fits XL 1982-1984; 58/65A drive gear side; steel / rubber; replaces OEM HD 29911-82; gross weight: 10 g

Oil seal; for Bearing / Armature / Generator; fits Big Twins 1946-1969, 750 cc 1946-1973, Sportster →1981; 32E and 58/65A drive gear side, Servi Car alternator drive; steel / rubber; replaces OEM HD 30145-46; gross weight: 10 g

Gasket by James Gaskets; for Generator; fits Big Twin 1958-1969, Sportster 1958-1984; to engine; paper; replaces OEM HD 30143-58; gross weight: 1 g

* United States of America: Tax free shipping. Please check your local import fees.
