Tsubaki

Headquartered in Kita-ku, Osaka, Japan, Tsubaki was founded in 1917 and is a global leader in secondary chains. Originally a bicycle chain manufacturer, the company quickly shifted focus to industrial-grade machine chains. With over 100 years of experience and continuous innovation, Tsubaki now produces more than 20,000 different types of chains.

Visit Website 

Products by Tsubaki in our web shop:

Tsubaki Delta 530 Secondary Chain

The Delta QRN 530 is a high-quality motorcycle roller chain without O-rings. The bushings made of oil-impregnated sintered material (HSL) provide optimized lubrication, resulting in extended service intervals and long service life. The nickel-plated outer plates ensure effective corrosion resistance and give the chain a clean, durable appearance. This makes the Delta QRN 530 a robust 530 chain, ideal for Harley-Davidson models and other motorcycles with a 530 chain drive.

Tsubaki Alpha RQ2 530 Secondary Chain

The Alpha type chain by Tsubaki is smooth running with a minimum of power loss combined with the benefits of X-sealed inside lubrication that provides a longer chain lifespan. A great chain for hi-torque, hi-horsepower performance bikes. Available as Alpha XRS in plain steel and RQ2 with gold coloured outer links. Same chain, same quality.

Tsubaki Sigma 530 Secondary Chain

The Sigma XRS 530 is the highest strength chain available from Tsubaki. While the steel coloured version keeps this name, the version with gold coloured outer plates changed it to RQ1. Quality and strength of course stay identic. The X-seals keep the factory-applied lube inside the bushings and minimize friction caused power loss. The choice for top horsepower bikes.

Tsubaki 530 Rivet Type Master Links

Selection of full rivet chain links which require a special tool with matching head molder for closure.

Tsubaki 530 Clip Type Master Links

Tsubaki RQ2 520 Narrow Secondary Chains

The Alpha type chain by Tsubaki is smooth running with a minimum of power loss combined with the benefits of X-sealed inside lubrication that provides a longer chain lifespan. A great chain for hi-torque, hi-horsepower performance bikes. The narrow 520 size comes in with gold coloured outer links and is handy in all applications where space is a problem.

Tsubaki 520 Clip Type Master Links

Tsubaki Chain Lube

This chain lube is specially formulated for use on both sealed and non-sealed chains. A combination of oils, greases and solvents prevents corrosion and extends chain mileage.

Tsubaki Chain and Engine Cleaner

Specially formulated for use on all types of motorcycles. Removes heavy dirt, oil and grease deposits from chains , sprockets, frame and engines. Quick and easy to use and water soluble, so it can be washed or brushed off with water.

Secondary chain »Sigma XRS 530« by Tsubaki; steel / rubber, grey, X-Ring; width: 25.2 mm; number of links: 100; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.26 kg

Secondary chain »Sigma XRS 530« by Tsubaki; steel / rubber, grey, X-Ring; width: 25.2 mm; number of links: 102; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.31 kg

Secondary chain »Sigma XRS 530« by Tsubaki; steel / rubber, grey, X-Ring; width: 25.2 mm; number of links: 104; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.35 kg

Secondary chain »Sigma XRS 530« by Tsubaki; steel / rubber, grey, X-Ring; width: 25.2 mm; number of links: 106; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.39 kg

Secondary chain »Sigma XRS 530« by Tsubaki; steel / rubber, grey, X-Ring; width: 25.2 mm; number of links: 110; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.49 kg

Secondary chain »Sigma XRS 530« by Tsubaki; steel / rubber, grey, X-Ring; width: 25.2 mm; number of links: 120; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.7 kg

Secondary chain »Sigma RQ1 530 Sigma XRG 530« by Tsubaki; steel / rubber, gold / steel grey, X-Ring; width: 25.2 mm; number of links: 100; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.26 kg

Secondary chain »Sigma RQ1 530 RQ1 530« by Tsubaki; steel / rubber, gold / steel grey, X-Ring; width: 25.2 mm; number of links: 102; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.33 kg

Secondary chain »Sigma RQ1 530 RQ1 530« by Tsubaki; steel / rubber, gold / steel grey, X-Ring; width: 25.2 mm; number of links: 104; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.37 kg

Secondary chain »Sigma RQ1 530 Sigma XRG 530« by Tsubaki; steel / rubber, gold / steel grey, X-Ring; width: 25.2 mm; number of links: 106; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.39 kg

Secondary chain »Sigma RQ1 530 Sigma XRG 530« by Tsubaki; steel / rubber, gold / steel grey, X-Ring; width: 25.2 mm; number of links: 110; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.48 kg

Secondary chain »Sigma RQ1 530 RQ1 530« by Tsubaki; steel / rubber, gold / steel grey, X-Ring; width: 25.2 mm; number of links: 120; pitch: 530 (5/8" x 3/8” x 10.16); tensile strength: 45.1 kN; max. permitted horsepower: 200 hp; with rivet type master link; gross weight: 2.71 kg

Primary chain by Tsubaki; fits 45cui/750cc Models 1929-1973 (Solo Only); steel, 8-shape side plates; pitch: 315x2 (3/8” x 3/16" x 5.1 x 2); number of links: 100; replaces OEM HD 2001-29, and 40006-29; gross weight: 666 g

Primary chain by Tsubaki; fits 45cui/750cc Models 1929-1973 (Solo Only); steel, 8-shape side plates; pitch: 315x2 (3/8” x 3/16" x 5.1 x 2); number of links: 102; replaces OEM HD 2001-29A; gross weight: 684 g

Primary chain by Tsubaki; fits 4-Speed Big Twin, Softail →2006, Dyna →2005; steel, oval side plates; pitch: 425x2 (1/2” x 5/16” x 8.51 x 2); number of links: 82; replaces OEM HD 40007-36B; gross weight: 1.6 kg

Primary chain by Tsubaki; fits Touring models →2006 and FXR with 5-Speed transmission; steel, oval side plates; pitch: 425x2 (1/2” x 5/16” x 8.51 x 2); number of links: 76; replaces OEM HD 40037-79A; gross weight: 1.48 kg

Primary chain by Tsubaki; fits Touring models 2007-2017; steel, oval side plates; pitch: 425x2 (1/2” x 5/16” x 8.51 x 2); number of links: 86; replaces OEM HD 40037-07; gross weight: 1.67 kg

Primary chain by Tsubaki; fits Softail 2007→, Dyna 2006→; steel, oval side plates; pitch: 425x2 (1/2” x 5/16” x 8.51 x 2); number of links: 92; replaces OEM HD 40036-06; gross weight: 1.79 kg

Primary chain by Tsubaki; for Cannonball StealthStarter Clutch Drive; steel, oval side plates; pitch: 425x2 (1/2” x 5/16” x 8.51 x 2); number of links: 84; gross weight: 1.63 kg
