Morris Magneto

Morris Magneto

There are few products on the HD aftermarket which became iconic but Morris Magnetos certainly are among them and have been the favoured choice of sporting riders since decades. Magneto ignitions have a long tradition with Milwaukee’s finest on both street and race motorcycles and in their heyday were considered as the performance ignition of choice. Admittedly, today with space age, programmable, digital multi-spark battery ignitions, magnetos appear somewhat outdated but if you are looking for a reliable, powerful and simple ignition system, a magneto is still an option. Besides, it looks as cool as cool can be.

Battery ignitions depend on a charging system, battery and coil to create a spark, with wires scattered all over your motorcycle. In contrast, a Morris Magneto’s charge comes directly from a self-contained spinning magnet - straightforward and effective. The W&W selection includes magnetos for a wide model range. Mag housings and, where applicable, the gear covers are machined from billet aluminum; standard finish is “as machined”, however, some versions are available polished. All kits come complete with necessary hardware and mounting instructions.

Visit Website

Products by Morris Magneto in our web shop:

Morris FMZ Magneto
Morris FMZ Magneto
An economic way to equip your vintage IOE Harley-Davidson and other 45° V-Twins with a more modern and reliable Fairbanks-Morse type magneto. Actually it is a tried and trusted Morris mag merged with the Bosch ZEV style base mount. Driven by the stock magneto gear which is also available and mounted with 3/8”-16 bolts to the crankcase. Comes with MRA advance-retard system. An easy conversion at a great price and OK'd to be used as an ignition for Motorcycle Cannonball cross country races.
more …
Morris Magneto MM74E for OHV Big Twins 1936-1969
Morris Magneto MM74E for OHV Big Twins 1936-1969
The MM74E-type magnetos are mounted at a forward angle, replacing the stock distributor. They fit Knucklehead, Panhead, and Shovelhead engines from 1936 to 1969. Timing is manually set to full retard for starting, and—if the mounting screws are correctly adjusted—the unit automatically advances to full timing once the engine is running. On original engine cases up to and including 1964, we recommend mounting the magneto to the side. Mounting it in the forward-facing position requires grinding off the casting lug above the generator mount.
more …
Morris Magneto MM3 for Sidevalves and Sportsters →1970
Morris Magneto MM3 for Sidevalves and Sportsters →1970
The MM3-type magnetos are mounted upright in place of the stock distributor. They fit flathead models from 1937 onward and Sportsters from 1957 to 1970. Timing is set manually to full retard for starting, and — if the mounting bolts are properly adjusted — the magneto will automatically rotate to the advanced timing position after the engine fires. Morris MM3 magnetos are a convenient replacement for well-aged original XLCH magnetos (29505-67).
more …
Morris Magneto Model G5 for OHV Big Twins 1936-1969
Morris Magneto Model G5 for OHV Big Twins 1936-1969
The Morris G5 magneto fits all Knucklehead, Panhead, and Shovelhead engine cases from 1936–1969, as well as the corresponding aftermarket cases, replacing the stock ignition distributor. It features a recoil spring-loaded mechanism that automatically releases and spins the rotor fast enough during starting to reliably generate a spark at the plugs. The offset housing makes installation easier—no interference with pushrod tubes or the relay boss.
more …
Morris Magneto Model H5 for Generator Style Crankcase
Morris Magneto Model H5 for Generator Style Crankcase
Like on the H-D factory XR race bikes, this magneto mounts to the generator port. The Morris G5 fits all Big Twin engine cases with an open generator mount. Like all magnetos, it does not produce any current for lights, horn, or other electrical accessories—so if you're riding on the street, you’ll need to come up with an adequate lighting solution. The G5 features a fully automatic recoil spring coupling system for easy starting, whether by kick or electric starter. Installation may require minor modifications to the engine case. The magneto body can be mounted in various positions to avoid contact with exhaust pipes or cylinders.
more …
Morris Magneto Model M5 for Big Twin 1973-1999
Morris Magneto Model M5 for Big Twin 1973-1999
The Morris M5 magneto comes with its own cam cover. The magneto itself features the same spring-loaded impulse mechanism as the other Morris 5-series units. This system spins the rotor up to speed during starting, ensuring a reliable spark at the plugs every time. The Morris M5 fits all Shovelhead and Evo Big Twin engines from 1970 to 1999.
more …
Single Fire Adapter
Single Fire Adapter
In-line polarizing solid state adapters to convert your magneto to single-fire operation. Use one kit for for single or two kits for dual plug applications. With each set-up only the live cylinder fires. Works with all Harley magnetos.
more …
Morris MRA Advance-Retard Kit
Morris MRA Advance-Retard Kit
The MRA is a revolutionary new device which aids starting by retarding the timing on fixed-position magnetos, helping to turn the infamous kick-backs and spit-backs into starts. When the cap-mounted lever is flipped, the points 'shift' 10 degrees, retarding your timing 20 degrees for starting. When the motor runs the lever is then locked in the advanced position by a rare-earth magnet. You'll love it! Fits clockwise turning Morris magnetos and other identically constructed magnetos like Joe Hunt, Fairbanks, etc. with cast housings.
more …
Hardware Kit for MM74E Magnetos
Hardware Kit for MM74E Magnetos
Screw, springs, nuts and washers that you need to mount and adjust a Morris MM74E magneto.
more …
Return Springs
Return Springs
more …
Oil Seals for Morris Magneto Shafts
Oil Seals for Morris Magneto Shafts
more …
Retaining Ring Rotor Shaft
Retaining Ring Rotor Shaft
more …
Morris Sparky Tool
Morris Sparky Tool
With this smart tool you can quickly check if your magneto produces a spark or not. If you position the "Sparky" close to an ignition wire and the blue light comes on, the magneto produces a spark. Very helpful when you want to exclude the magneto as the cause of an ignition problem. This tool has been calibrated specifically for magnetos, but will work on just about anything that sparks.
more …
13-145
13-145
Ignition coil by Morris Magneto; for Magneto; fits XLCH 1958-1969, Morris and Joe Hunt magnetos; red; with springs; replaces OEM HD 29524-55A; USA; gross weight: 320 g
more …
13-271
13-271
Ball bearing by Morris Magneto; for magneto rotor; lower; steel; tolerance class: ABEC 1; ID x OD: 15 x 35 mm, 9 mm thick; replaces OEM HD 29563-55; gross weight: 46 g
more …
57-574
57-574
Gasket by Morris Magneto; for Lid / Magneto; fits XLCH 1958-1969; fits also Morris and Hunt magnetos; paper / silicone; gross weight: 12 g
