Gasket by James Gaskets; for Carburetor / Manifold; for 1-1/2” Linkert carburetors and manifolds; fits OHV Big Twins 1940-1965, WLDR/WR 1940-1948, K/KR 1952-1965; paper; replaces OEM HD 27411-40, and 27410-52; gross weight: 1 g

Reproductions of the stock hex head bolts to fasten Linkert carburetors to the manifold.

A custom part with a long tradition. This smart little device allows for the use of pull type throttle assemblies with Linkert carbs. After installation the throttle disc will be pulled to open and the spring closes it again, when you release the throttle grip. Each kit comes with two springs to meet individual requirements. The weaker spring (Fn≈23 N) should be sufficient for most outside cable applications, the stronger spring (Fn≈58 N) is recommended for internal or very long throttle cables. Works with all M-series Linkert carbs, when equipped with a 1949-1965 type lever, i.e. OEM# 27260-49.

These are the seals many of you have heard about, which will once and for all cure the notorious intake leaks of old manifolds. They are machined from PEEK (polyetheretherketone), a thermoplastic with a melting point of 650°F (343°C). Compared to brass seals this material has superior creep resistance and seal properties and can sustain large stresses over a long service life without significant extrusion.
