KNIPEX

Knipex-Werk C. Gustav Putsch KG, KNIPEX for short, is a manufacturer of high-quality pliers for users in craft and industry. The company is headquartered in Wuppertal. KNIPEX has been an owner-managed family business for four generations. It manufactures exclusively in Germany and is one of the world's leading producers of its kind.

Visit Website 

Products by KNIPEX in our web shop:

Knipex Insulation Stripper

Compact tool for single, multiple and fine stranded wires of 0.2 up to 6 mm² (AWG 24-10) cross-sections with standard PVC insulation. It adapts automatically to the respective cable cross-section and prevents damage to the conductor. The handy shape and low weight provide high operation comfort. With its narrow head style it can also be used in confined areas. An integrated with wire cutter cuts copper and aluminium wires up to 2.5 mm². The length stop can be adjusted from 6.0 - 18.0 mm for cutting the same stripping lengths during repetitive work. The body is made from fibreglass-reinforced plastic, the interchangeable blades are made from special oil-hardened tool steel.

Knipex Wiring Pliers

In addition to their function as needle-nosed pliers these pliers are ideal when you are working on your wiring harness. They grip, bend and cut medium hard and hard wire with precision, induction hardened cutting edges (hardness approx. 60 HRC). They also feature three stripping holes and four positions for crimping end sleeves (ferrules). Made from forged and oil-hardened Vanadium electric steel.

Knipex Pliers Wrenches

Excellent for gripping, holding, pressing and bending workpieces and for careful installation of components with delicate surfaces. The zero backlash jaw pressure prevents damage to edges. Fast adjustment by pushing a button directly on the workpiece. These pliers replace a complete set of spanners with their parallel jaws, which allow infinitely variable gripping of all widths to the specified maximum size. Screwed connections can be tightened and released quickly by using the ratchet principle. The lever transmission ratio is about 10:1 for strong gripping power.

Knipex Grip Pliers Universal

Every toolbox should contain one. They hold rounded nuts and bolts, axles, cables, springs, or you name it. These grip pliers by Knipex are heavy duty and will give you years of service. They feature an adjustment screw and release lever. With their toggle lever action they provide very high clamping pressure. The body is made from high-strength rolled steel, the gripping jaws are forged from chrome vanadium electric steel.

Knipex Grip Pliers Long Nose

Daddy’s little helper in the workshop or in your tool roll. Holds rounded nuts and bolts, pins, cables, springs, or you name it. These long nose grip pliers by Knipex are of professional quality and will give you years of service. They feature an adjustment screw and release lever. With their toggle lever action they provide high clamping pressure. The body is made from high-strength rolled steel, the gripping jaws are forged from chrome vanadium steel.

Knipex Water Pump Pliers

Professional pliers which allow fast adjustment directly on the workpiece. The fine adjustment ensures optimum adjustment to differently sized workpieces and a user-friendly handle position. Guards prevent operators’ fingers being pinched and a favourable lever action results in optimum transmission of force. The self-locking function on pipes and nuts prevents slipping on the workpiece and lowers the required handforce. Gripping surfaces feature special hardened teeth (approx. 61 HRC). Made from chrome vanadium electric steel, forged and oil-hardened

Knipex Combination Pliers

A true classic for your workshop or tool roll. Combination pliers made from special tool steel, forged and oil-hardened. Feature gripping zones for flat and round material, suitable for versatile use. The induction hardened cutting edges (hardness approx. 60 HRC) bite hard wires and thicker cables without problems.

Knipex Needle Nose Pliers

No workshop is complete without a pair of needle-nose pliers with their wide range of uses! Especially in deep and hard-to-reach places, this tool with its long, grippy, pointed jaws often helps you out of trouble. An induction-hardened cutting edge (approx. 61HRC) at the end of the jaws makes it easy to cut through medium hard (Ø 3.2mm) and hard wires (Ø 2.2mm). Made from forged and oil-hardened Vanadium electric steel.

Knipex Mounting Pliers

These extra-long mounting pliers with special jaw profile enable, in addition to their function as a long needle-nose pliers, the safe gripping and guiding of objects with a round profile, such as screws, pipes, cables or other round objects. The grooves milled into the jaw profile have a smooth surface, which is gentle on the workpiece. The long handles allow a lot of force to be exerted with little effort. Made of forged steel, hardened in oil.

Knipex CoBolt S Compact Bolt Cutters

These little beef-cakes easily cut bolts, wires, rivets etc. up to Ø 4.4 mm. Harley clutch, brake or throttle cables for example, can be shortened without problems. A most efficient joint design ensures exceptional cutting performance with little effort. The forged chrome vanadium steel construction features precision cutting edges, oil-hardened to approx. 64 HRC and with a microstructure to keep the material to be cut in a good position. A gripping surface below the joint allows for gripping and pulling wires with a diameter > 1.0 mm. Grips are covered with vinyl.

Knipex Diagonal Side Cutters

The indispensable diagonal cutter for all-round use. It features precision induction hardened (approx. 62 HRC) cutting edges for soft (Ø 4mm) and hard wires (Ø 2mm). The narrow head style allows trouble-free use in confined areas. Made from vanadium electric steel, forged and oil-hardened.

Knipex Bowden Cable Cutters

Special pliers for Bowden cables and wire rope up to 3.0 mm Ø (also stainless). Smooth and clean cutting with induction hardened cutting edges whose special shape surround the material and prevent the wires from fanning out. Require only small handforce due to excellent transmission ratio. With opening spring and locking lever. Made from high-grade special tool steel, forged and oil-hardened.

Knipex Retaining Ring Pliers

Special pliers for fitting circlips. They feature inserted spring steel wire tips for a long service life. The slim head style allows use in confined areas and a precise screw joint guarantees smooth operating. Large contact faces on the tips prevent distortion of circlips. The body is made from chrome vanadium electric steel, forged and oil-hardened. Handles with non-slip plastic coating.

Knipex Snap Ring Pliers

Special pliers for fitting horseshoe-shaped spring retaining rings and circlips without grip holes. Made from chrome vanadium electric steel, forged, oil-hardened. Works for retaining rings with a minimum ring split gap of 3.6 mm.

Knipex Protective Jaws

Protective jaws for Knipex pliers wrenches. Thanks to their soft and smooth surface, they prevent sensitive materials such as aluminium or chrome coatings from being scratched. Easy to attach by hand and securely fixed to the pliers jaws by internal locking hooks. Consisting of three protective jaws each for the lower and upper pliers jaw.

Knipex Combination Shears

Need an emergency gasket for your motorcycle? Cut your own! The Knipex combination shears are great assistants for cutting cardboard, plastics, aluminium, brass and copper foils. Their blades are made from stainless, vacuum-hardened surgical steel, precisely ground, with an adjustable bolted joint. With opening spring for easy operation and lock for safe storage. The ergonomically shaped, impact-proof handles ar made of plastic

Retaining ring pliers by KNIPEX; for 19-60 mm; for retaining rings inside (closing); parkerized; length: 180 mm; Germany; gross weight: 180 g

Retaining ring pliers by KNIPEX; for 40-100; for retaining rings inside (closing); parkerized; length: 225 mm; Germany; gross weight: 270 g

Retaining ring pliers by KNIPEX; for 3-10 mm; for retaining rings outside (opening); parkerized; length: 140 mm; Germany; gross weight: 100 g

Retaining ring pliers by KNIPEX; for 19-60; for retaining rings outside (opening); parkerized; length: 180 mm; Germany; gross weight: 180 g

Retaining ring pliers by KNIPEX; for 3-10 mm; for retaining rings outside (opening); parkerized; length: 130 mm; Germany; gross weight: 100 g
