CPV

CPV Ball Milled Timer Covers

more …

Steering Head Cups 3° Rake

Longer fork tubes inevitably result in the bike's front end going up. These special neck cups offer a simple way to reduce this problem. Their sophisticated design adds 3 additional degrees to your frame neck and your bike sits much better levelled to the ground again in no time.

more …

CPV Cups with Integrated Stops

Custom frames and triple trees often come without fork stops which usually requires to modifications to the beautiful trees and/or to weld fork stops to the frame. Our frame cups with integrated stops make this a problem of the past. An ingenious stopping plate system hides the complete action inside the frame cups. Requires drilling and tapping of 4 holes into the lower triple tree.

more …

CPV Offset Spacers for Brake Rotors

Selection of spacers for Evolution and Twin Cam models to achieve the required offset in most any situation.

more …

CPV Offset Spacers for Rear Sprockets and Pulleys for Models 2000→

Selection of spacers for Evolution and Twin Cam models to achieve the required offset in most any situation.

more …

CPV Bullet Oil Tank Plug

more …

CPV Oil Filter Bracket

Oil filter backing plate which is machined from billet aluminum and features two m8 studs for universal mounting.

more …

CPV End Cap for 4” SuperTrapp

This open end cap fits all 4” SuperTrapp mufflers with internal disc system. It is machined from billet aluminum and has a satin finish.

more …

CPV Derby Cover

Polished billet aluminum covers with ball-milled grooves.

more …

CPV Inspection Cover

Polished billet aluminum covers with ball-milled grooves. The inspection cover fits 4-speed FL and FX models with forward controls from 1965 thru 1986 and all Softail or Dyna Wide Glide models from 1984 to present.

more …

26-083

Wheel hub flange offset spacer by CPV; for Brake rotor; fits models 1973-1999 except FX/XL with narrow front hub 1973-1983; billet aluminum; Ø centering collar: 50 mm; outer Ø: 108 mm; offset: 1/4 ”; max. Ø of mounting bolts: 3/8”; gross weight: 140 g

more …

26-085

Wheel hub flange offset spacer by CPV; for Brake rotor; fits models 1973-1999 except FX/XL with narrow front hub 1973-1983; billet aluminum; Ø centering collar: 50 mm; outer Ø: 108 mm; offset: 3/8 ”; max. Ø of mounting bolts: 3/8”; gross weight: 230 g

more …

26-087

Wheel hub flange offset spacer by CPV; for Brake rotor; fits models 2000→; billet aluminum; Ø centering collar: 56 mm; outer Ø: 108 mm; offset: 1/4 ”; max. Ø of mounting bolts: 3/8”; gross weight: 130 g

more …

26-088

Wheel hub flange offset spacer by CPV; for Brake rotor; fits models 2000→; billet aluminum; Ø centering collar: 56 mm; outer Ø: 108 mm; offset: 5/16 ”; max. Ø of mounting bolts: 3/8”; gross weight: 180 g

more …

26-089

Wheel hub flange offset spacer by CPV; for Brake rotor; fits models 2000→; billet aluminum; Ø centering collar: 56 mm; outer Ø: 108 mm; offset: 3/8 ”; max. Ø of mounting bolts: 3/8”; gross weight: 230 g

more …

26-117

Wheel hub flange offset spacer by CPV; for Brake rotor; fits models 2000→; billet aluminum; Ø centering collar: 56 mm; outer Ø: 108 mm; offset: 1/2 ”; max. Ø of mounting bolts: 3/8”; gross weight: 300 g

more …

26-118

Wheel hub flange offset spacer by CPV; for Brake rotor; fits models 2000→; billet aluminum; Ø centering collar: 56 mm; outer Ø: 108 mm; offset: 3/4 ”; max. Ø of mounting bolts: 3/8”; gross weight: 430 g

more …

26-125

Wheel hub flange offset spacer by CPV; for Brake rotor; fits models 2000→; billet aluminum; Ø centering collar: 56 mm; outer Ø: 108 mm; offset: 7/8 ”; max. Ø of mounting bolts: 3/8”; gross weight: 510 g

more …

26-119

Wheel hub flange offset spacer by CPV; for Brake rotor; fits models 2000→; billet aluminum; Ø centering collar: 56 mm; outer Ø: 108 mm; offset: 1 ”; max. Ø of mounting bolts: 3/8”; gross weight: 580 g

more …

26-123

Wheel hub flange offset spacer by CPV; for Brake rotor; fits models 2000→; billet aluminum; Ø centering collar: 56 mm; outer Ø: 108 mm; offset: 1-3/16 ”; max. Ø of mounting bolts: 3/8”; gross weight: 700 g

more …

50-029

Filler plug »Bullet« by CPV; for Oil tank; for 1-5/16” ID filler spout; fits Softail Twin Cam ; with dipstick; aluminum, polished; Europe; gross weight: 200 g

more …

50-035

Filler plug »Bullet« by CPV; for Oil tank; for 1-5/16” ID filler spout; fits Softail Twin Cam ; with dipstick; aluminum, black; Europe; gross weight: 170 g

more …

50-018

Filler plug »Bullet« by CPV; for Oil tank; for 1-1/4” ID filler spout; fits Softail Evolution; with dipstick; aluminum, polished; Europe; gross weight: 150 g

more …

50-026

Filler plug »Bullet« by CPV; for Oil tank; for 1-1/4” ID filler spout; fits Softail Evolution; with dipstick; aluminum, black; Europe; gross weight: 150 g

more …

50-012

Filler plug »Bullet« by CPV; for 1-1/4” ID filler spout; without dipstick; aluminum, polished; Europe; gross weight: 130 g

more …

50-015

Filler plug »Bullet« by CPV; for 1-1/4” ID filler spout; without dipstick; aluminum, black; Europe; gross weight: 120 g

more …

29-166

Distributor fitting by CPV; for Brake line; aluminum, polished; length: 130 mm; connection thread: 2 x 3/8”-24; gross weight: 110 g

more …

29-289

Distributor fitting by CPV; for Brake line; aluminum, black, anodised; length: 130 mm; connection thread: 2 x 3/8”-24; gross weight: 10 g

more …
