Braking

The ”Wave” disc differs from standard discs in quite a few features. Firstly the outside diameter is shaped to provide extra pad cleaning ability. The wave shapes of the exterior diameter and of the inner profile of the braking track allow the disk to expand without deforming. Basically the disc is always perfectly flat. The know-how regarding material and applied working cycle allow to obtain perfect discs in all aspects. Strong initial grip with still good control, Constant backing on three points, with parallel wear of the pad, Peripheral surface with greater heat dissipation, Possibility of expansion on the medium circumference, thus avoiding conic deformation, Less weight, Continuous variation of the braking section which allows the pad ”to float” without getting pasted to the track,

Feature carbon steel ring mounted on a stainless steel carrier.

The 5 spoke design comes in a ground machine finish.

Brake pads by Braking; for normal use; fits XR 1200 2009→; steel / friction compound, SM1; position: front; replaces OEM HD 42739-08; gross weight: 260 g

Brake pads by Braking; for street & racing; fits XR 1200 2009→; steel / friction compound, CM55; position: front; replaces OEM HD 42739-08; gross weight: 260 g

Brake rotor »5 Spoke Full Floater« by Braking; fits wheels 1984-1999; carbon steel / stainless steel, ground; Ø 11.5”; position: front; mounting holes: 5/16” flat counterbore; inner Ø: 50 mm; with german national homologation; gross weight: 2 kg

Brake rotor »5 Spoke Full Floater« by Braking; fits wheels 2000→; carbon steel / stainless steel, ground; Ø 11.5”; position: front; mounting holes: 5/16” flat counterbore; inner Ø: 56 mm; with german national homologation; gross weight: 2.02 kg

Brake rotor »5 Spoke Full Floater« by Braking; fits wheels 1984-1999; carbon steel / stainless steel, ground; Ø 11.5”; position: rear; mounting holes: 3/8" flat counterbore; inner Ø: 50 mm; with german national homologation; gross weight: 1.98 kg

Brake rotor »5 Spoke Full Floater« by Braking; fits wheels 2000→; carbon steel / stainless steel, ground; Ø 11.5”; position: rear; mounting holes: 3/8" flat counterbore; inner Ø: 56 mm; with german national homologation; gross weight: 2.01 kg

Brake rotor »5 Spoke Solid« by Braking; fits wheels 1984-1999; carbon steel, ground; Ø 11.5”; position: front; mounting holes: 5/16” flat counterbore; inner Ø: 50 mm; with german national homologation; gross weight: 1.98 kg

Brake rotor »5 Spoke Solid« by Braking; fits wheels 2000→; carbon steel, ground; Ø 11.5”; position: front; mounting holes: 5/16” flat counterbore; inner Ø: 56 mm; with german national homologation; gross weight: 1.86 kg

Brake rotor »5 Spoke Solid« by Braking; fits wheels 1984-1999; carbon steel, ground; Ø 11.5”; position: rear; mounting holes: 3/8" flat counterbore; inner Ø: 50 mm; with german national homologation; gross weight: 2 kg

Brake rotor »5 Spoke Solid« by Braking; fits wheels 2000→; carbon steel, ground; Ø 11.5”; position: rear; mounting holes: 3/8" flat counterbore; inner Ø: 56 mm; with german national homologation; gross weight: 1.93 kg

Brake pads by Braking; fits XR 1200 2008→; steel / friction compound, CM88; position: rear; replaces OEM HD 42310-08; gross weight: 300 g

Brake pads by Braking; for 125x2 and 125x4S calipers; steel / friction compound, SM1; gross weight: 80 g
